CAM-180-HE

SPECIFICATIONS AND FEATURES

SPECIFICATIONS:

HEAT INPUT CAPACITY: 180,000BTU

EFFICIENCY: 87.10%

NET OUTPUT: 157,000 BTU

RATED AIR FLOW: 1,475 CFM TO .7 IN W/C

FAN STATIC PRESSURE: .7 IN W/C

FUEL TANK CAPACITY: 26.5 US GAL

FUEL CONSUMPTION: 1.28 US GAL/HR

RUNNING ENDURANCE TIME: 20 HR

FUEL TYPES: KEROSENE, #1 FUEL OIL OR #1 DIESEL, JP8, JP4, JP5

POWER SUPPLY: 110V-60 HRZ (STANDARD) , 230V-50 HRZ (CUSTOM)

POWER CONSUMPTION: 460W

NOISE LEVEL AT 3 FT.: 75 DB

MAX OUTPUT TEMPERATURE: 240 F

TEMPRATURE RAISE: 130 F

FLUE DIAMETER: 6 IN

WEIGHT AND DIMENSIONS: 192 LBS (DRY WEIGHT) 55" L X 21" W X 30" H

DUCTING: 12" DIAMETER, INPUT AND OUTPUT WITH "J" LOCKS

FEATURES:

* STACKABLE

* FOUR WAY FORKLIFTABLE

* EXTERNAL FUEL SYSTEM

* STORAGE COMPARTMENT

* REMOTE THERMOSTAT
